Engine model:RATO R740D/RATO R420D
Fuel type:Gasoline
Cylinders :2/1
Displacement cc:740/420
Emission standards :EU Stage V&EPA Tier 4 Final
Cooling system :Air
Operating voltage V:12
Battery Ah:24
Lifting capacity,max kg:350
Steering angle°:0-360
Standard tires :18×9.50-8
Working hydraulic flow I/min :21
Working hydraulic pressure bar :160
BucketCapacity：0.3m³
Lifting Height ofmain boom：3000mm
Dumping reach of main boom：587mm
Max. Loading capacity of main boom:800kg
Lifing height of small boom:3600mm
Dumping reach of small boom:1085mm
Max.Loading capacity of small boom：600kg
Max. Speed(F1/R1):12km/h
Max.Traction force:16.66KN
Max. Breakout Force:15KN
Overall Height:2310mm
Maximum Load:600kg
Net Weight of Vehicle Body:1200kg
Articulated Turning Angle:45°
Climbing Gradient:30%
Hydraulic Oil Tank Capacity:32L
Diesel Oil Tank Capacity:24L
Working Hydraulic Flow:36L/min
Total Length of Vehicle Body:3290mm
Wheel Spacing:1260mm
